Product Description

Detect deeper. Identify sharper. Recover faster.

The Manticore with Multi-IQ+ technology is the fastest, most powerful and most precise metal detector Minelab has ever built. Multi-IQ+ pushes greater power through the coil across a wider frequency range, helping you pull more targets out of the ground. With advanced signal processing, higher accuracy and faster recovery, the Manticore sets a new benchmark for serious treasure hunters.

Key Highlights

Powerful Multi-IQ+ engine: Enhanced discrimination and sharper target separation with high-precision identification.
Advanced 2D target ID map: A visual identification system that combines ferrous and conductivity properties for smarter digging decisions.
10 dedicated search modes: Profiles for all-terrain, beach and gold-field detecting.
Fast response: Adjustable recovery speed (0–8) to separate close targets or increase depth.
Enhanced discrimination: Custom ferrous cut-off levels and stable target identification.
Audio your way: Flexible tone options, zones, an all-tones mode and VCO support.
Unmatched build quality: IP68 waterproofing to 5 metres, a carbon-fibre shaft and a full-colour LCD display.

Detection Systems & Modes

Multi-IQ+ (Simultaneous Multi-Frequency)

A next-generation SMF engine with greater power and a wider frequency range for enhanced depth and clarity.

2D Target ID Map

A dual-axis display that shows ferrous and conductivity properties together, helping you decide faster and dig smarter.

10 Search Modes

All-Terrain (5), Beach (4), Gold Field (1). Fully customisable search profiles.

Technical Specifications

Operating Frequency 5, 10, 15, 20 & 40 kHz, Multi-IQ+®

Sensitivity 1 – 35

Noise Cancel Automatic, continuous automatic, manual

Wireless Audio Low-latency wireless audio

Volume Control 0 – 25

Iron Volume 0 – 25

Target Tones 1, 2, 5 tones; 1, 2, 5 zones; all tones

Included Headphones ML105 wireless headphones

Audio Outputs Speaker, wired 3.5mm, low-latency wireless

Discrimination Segments 2D ID: 100 conductivity, 50 ferrous

Target ID 2D ID: 0 – 99 with ferrous indication

Depth Indicator 5 levels

Length Extended: 144 cm (56.7 in), Collapsed: 63 cm (24.8 in)

Weight 1.3 kg (2.9 lb)

Waterproofing IP68 — waterproof up to 5 metres (16 ft)

Display Full-colour LCD

Screen Backlight White (1–10, auto-brightness)

Keypad Backlight White (high, medium, low, off, auto)

Flashlight Low, medium, high, off

Vibration Proportional, off

Core Technology Multi-IQ+

Warranty 3 Years (control box and coil)

Box Contents

The standard package includes:

Standard coil: M11 11-inch round Double-D

Included battery: internal 3.7V / 6800mAh lithium-ion

Included accessories: M11 coil, ML105 wireless headphones with audio cable and hard case, and 5 display protectors

Accessories (Optional)

Magnetic USB charging cable

EQX 3.5mm waterproof phone adapter cable

Equinox 3.5mm waterproof headphones

8x5.5-inch elliptical Double-D coil (M8)

ML105 low-latency wireless headphones

11-inch round Double-D coil (M11)

9-inch round Double-D coil (M9)

Spare battery (25Wh lithium-ion)

User Manual & Getting Started

Download the official documentation for the Manticore:

User Manual - Manticore Getting Started Guide - Manticore
